Pipeline construction Expert 7.4 according to EN

Excluding VAT (19%)plus Shipping costs
Delivery time:

2-5 business days
 Pieces
Add to cart

Tabs



Pipeline construction expert 7.4 according to EN includes:



- Dimensions for:

   a)  the coilings and the cut length for direct transfer onto the pipe for segmented bend, attached, inserted, offset and inclined nozzles, - mass unlimited

   b) nozzle on elbow according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, nominal sizes from DN15 to DN1200, model 2D, 3D and 5D, and according to DIN 11852 series 1 and 2, nominal sizes from DN10 to DN250

   c) nozzle on reducer according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, nominal sizes from DN15 to DN1200

   d) transitional body rectangle-circle

   e) true "Y"




You only need to enter the overall dimensions in a complete work plan (green box) and the program calculates the rest.









Calculations of intersections with standard elbows according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, nominal sizes from DN15 to DN1200, model 2D, 3D and 5D, according to DIN 11852 series 1 and 2, nominal sizes from DN10 to DN250, and with other elbows and without elbows - mass unlimited. This are:

   a) wewld to weld intersection,
   b) intersection with 2 standard elbows,
   c) intersection with 90 deg. Elbow ,
   d) intersection with tee and elbow,
   e) intersection with standard elbows,
   f) intersection with other elbows,
   g) intersection without elbows.








- Calculations of 36 three-dimensional intersections with standard elbows according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, nominal sizes from DN15 to DN1200, model 2D, 3D and 5D, according to DIN 11852 series 1 and 2, nominal sizes from DN10 to DN250, and with other elbows and without elbows - mass unlimited.











-Tables for pipe fitter with total lists of surface dimensions of flanges and buttwelding fittings to be laminated,






and elbow dimensions from 0,5 deg. to 90 deg. each 0,5 deg. according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, nominal sizes from DN15 to DN1200, model 2D, 3D and 5D, and according to DIN 11852 series 1 and 2, nominal sizes from DN10 to DN250.








- Database of all dimensions for flanges according to DIN EN 1092-1:2013-04 / EN 1092-1:2007+A1:2013, nominal sizes from DN10 to DN4000, nominal pressure from PN2,5 to PN400.











- Database of all dimensions for buttwelding fittings according to DIN EN 10253-2:2008-09 / EN 10253-2:2007, type A and B, nominal sizes from DN15 to DN1200. This are:

   a) Elbows model 2D, 3D and 5D,
   b) streigth and reducing outlet Tees,
   c) concentric and eccentric Reducers,
   d) Caps.











- Calculations of all sides and angles rectangular and nonrectangular triangles.











The program only works if Microsoft Excel from 2003 is installed on your computer.



To view, you can download the demo version here:



The program does not interfere in the registry. After using the program you uninstall it from your computer with the integrated Deinstallator, and you have no more traces of the demo program on your computer.
